Brass and Copper Tube Products

Brass and Copper Tube Products

IN STOCK AND AVAILABLE FOR IMMEDIATE SHIPMENT

PJ Tube’s brass and copper coils, as well as straight length tubing are available in a variety of shapes, standard and custom sizes. Inventory/stocking programs are available for customers requiring just in time delivery.

Copper and Brass Tubing

PJ Tube supplies copper and brass tube products in variety of grades and sizes, meeting a full range of temper and tolerance requirements. Our copper and brass tubing is available in mill lengths, custom lengths as well level-wound coils. In addition, we offer square copper and utility coils in standard 50-ft. lengths, individually packaged and boxed for quick shipping. We also offer precision cut tube to meet your specific, shorter length requirements.

PJ Tube provides C101, 102, 120, 122, 194 copper grades manufactured to ASTM B75, B280, B68, as well as other specifications. We also supply C443, 210, 220, 230, 260, 270, 272, 330, 332, 435 and other brass grades manufactured to meet a variety of specifications, including ASTM B135 (for pump barrels), B467, and B543/B543M. In addition to copper and brass, P&J Tube offers C706 (90/10), 715, 740, and 752 grades in its CuproNickel line of products.

Inventory/stocking programs are available for customers requiring just in time delivery. Customers looking for reliable copper or brass tubing solutions, delivered when they need them most, turn to PJ Tube, a dependable supplier since 1963.

Copper Utility Coil Stock List

PJ Part NumberSizeODWallWeight per Coil (lbs)
J0387712503050.125"OD X .030"W X 50'L SOFT CU (1/8")1/8".030"1.74
J0387718703050.1875"OD X .030"W X 50'L SOFT CU (3/16")3/16".030"2.88
J0387725003050.250"OD X .030"W X 50'L SOFT CU (1/4")1/4".030"4.02
J0387731203050.3125"OD X .032"W X 50'L SOFT CU (5/16")5/16".032"5.45
J0387737503050.375"OD X .032"W X 50'L SOFT CU (3/8")3/8".032"6.70
J0387750003050.500"OD X .032"W X 50'L SOFT CU (1/2")1/2".032"9.10
J0387762503050.625"OD X .035"W X 50'L SOFT CU (5/8")5/8".035"12.55
J0387775003050.750"OD X .035"W X 50'L SOFT CU (3/4")3/4".035"15.25
J0387787503050.875"OD X .045"W X 50'L SOFT CU (7/8")7/8".045"22.75
J03021000030.250" Square X .048"W X 50'L 1/4".048"7.50
J03021000050.375" Square X .048"W X 50'L3/8".048"12.14
